Tenaquip

Johnson

7-1/4" Johnny Square® MACH-1™ Smart Mark™ Rafter Square with Level Vial

Model: UBA594

Mfr. No.: 1904-0700V

See Product Details

  • Johnson 1904-0700V 7-1/4" Johnny Square® MACH-1 Smart Mark Rafter Square with Level Vial

Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

$43.00 / Each

Ships in 5-8 weeks

Shipping times are based on information available at the time of order and are subject to change.

FREE delivery on all orders over $150 when shipping to an eligible location.

Buy More, Save More

Quantity Price per
2-5 $41.71
6-13 $40.85
14-23 $40.42
24 or more $39.99

Related Products

Description

  • Speed meets precision with Johnson’s new Johnny Square® MACH-1™ rafter square with level vial – a must have tool engineered for professionals' providing exceptional durability, versatility and accuracy
  • Smart Mark™ Cutout delivers speed and accuracy with its easily identifiable markings, cutouts and notches for layout, scribing and marking cuts
  • Marking spaces are positioned to layout 1X, 2X, 4X and 6X lumber in widths from 1" to 6" as well as LVL's
  • Additional slots are positioned to mark 22.5, 30, 45 and 60 degree angle cuts
  • V-notches are located at each roof pitch to help accurately align your pencil when marking common top cuts
  • The frame has 1/16" scale graduations for precision and measures all the way to 7-1/4" to reach the full width of a 2x8 material
  • Scribe notches for ripping lumber are positioned every 1/8"
  • The 1" wide multifunctional heel with replaceable level vial serves as a torpedo to indicate level and plumb and allows angle or roof pitch measurements on existing structures
  • The heel also features 1/16" scale graduations on the bottom and both sides offering maximum versatility with rapid and reliable measuring
  • Hi-visibility EZ-Read™ graduations and numbers are laser etched deep into the surface to resistant fading, scratching or deterioration, providing long-lasting results even under tough and demanding work conditions
  • Crafted from solid aluminum with CNC machined edges and vial holder for ultimate precision and accuracy
  • The matte black anodized coating reduces glare in direct sunlight and provides protection from rust and corrosion

Specifications

Size

2" x 8"

Graduations

1/16"

Blade Material

Aluminum

Blade Finish

Anodized

Accuracy

0.001 in/ft or 1mm/m

Vial

(1) Barrel Vial

Angle Slots

22.5°, 30°, 45°, 60°

Heel Width

1"

Notch Increments

1/8"

Frame Height

7-1/4"

UPC

049448000524

Country Of Origin

China

Manufacturer's Warranty

  • Limited Lifetime
